Description
High Seasonal Efficiency A+++Â Rated
The NEW sleek design Mitsubishi Heavy Industries Air Conditioning SRK-ZSX-WF Diamond Plus wall mounted indoor units have a new ‘smooth line’ design which has a lower profile flatter smooth edge appearance, and is far more easier to keep clean. Choose your favourite colour from Pure white (WF), White and black (WFB) and Titanium (WFT). This series has a timeless, attractive look which integrates elegantly into any room, with its gently defined curved shape. It has a high A+++ energy saving performance thanks to the latest Mitsubishi inverter rotary compressor and latest ozone friendly R32 refrigerant. Using the “3D Auto” fan setting to achieve harmonised temperature as well as the jet-flow low noise air movement fan arrangement which provides a quiet airflow. The result is a quiet, high performance and energy efficient cooling and heating system, with advanced electronic controls for maximum comfort. The unit is PRE-CHARGED WITH REFRIGERANT for up to 15 metres with a maximum 20 metre pipe length.
| INDOOR UNIT c/w Controller | SRK50ZSX-WF, WFT, WFB | |
| OUTDOOR UNIT | SRC50ZSX-W2 | |
| UK Cooling | kW | 4.76 |
| UK Sensible Cooling | kW | 3.84 |
| Cooling Range (Nominal) | kW | 1.0 to 6.2 |
| S.E.E.R , EER, Energy Label | 8.3, 4.03, A++ | |
| Heating Range (Nominal) | kW | 0.8 to 8.2 |
| S.C.O.P , COP, Energy Label | 4.70, 4.41, A++ | |
| Annual electricity consumption c/h | kWh/a | 211/1341 |
| INDOOR UNIT | ||
| Exterior Dimensions (H x W x D) | mm | 305 x 920 x 220 |
| Net Weight | kg | 13 |
| Air Flow (H/M/L) Cooling | m3/m | 14.3 / 12.4 / 7.8 |
| Air Flow (H/M/L) Heating | m3/m | 17.3 / 14.3 / 9.8 |
| Sound Pressure Level (H/M/L) Cooling | db(A) | 44 / 39 / 31 |
| Sound Pressure Level (H/M/L) Heating | db(A) | 47 / 41 / 33 |
| OUTDOOR UNIT | ||
| Exterior Dimensions (H x W x D) | mm | 640 x800(+71)x290 |
| Net Weight | kg | 45 |
| Sound Pressure Level Cooling/Heating | db(A) | 51 / 49 |
| ELECTRICAL DATA | ||
| Power Source Rating MCB | A | 20 |
| Mains Power To | Outdoor | 230V/1ph/50Hz |
| Interconnecting Wires (Dia) | (mm2) | 3+E (1.5) |
| Start Current / Max Running Current | A | 5 / 15 |
| INSTALLATION/REFRIGERANT | ||
| Ref. Piping Size o.d.ins (mm) | Liquid | 1/4 (6.35) |
| Suction | 1/2 (12.7) | |
| Ref. Max Piping Length | m | 30 |
| Vertical Height Difference (Max)*Outdoor Unit Above/Below Indoor Unit | m | 20 / 20 |
| Refrigerant Amount Pre-charged | kg/ TCO2Eq | 1.30 / 0.87 |
| * For Pipe Length Up To | m | 15 |
| Additional Refrigerant | g/m | 20 |
These air conditioning units must be installed by an F-Gas qualified engineer. ( We will ask to view this certificate before the shipment) We can install the unit for you using our F-Gas Certified Engineers.
