Mitsubishi Heavy Duty Multi-Split Heat Pump System – SCM100ZS-S Outdoor Unit with 4 x SRK15ZSP-W Wall-Mounted Indoor Units

Mitsubishi Heavy Industries Air Conditioning SCM100ZS-S 4 x SRK35ZSP-W Wall Heat pump pump

£2,790.00 ex. VAT

Mitsubishi Heavy Industries Air Conditioning SCM100ZS-S 4 x SRK35ZSP-W Wall Heat pump 3.5Kw/12000Btu

Product Key Features:
• High CoP, up to 3.82
• New advanced technology control
• Infra-red controller with wall mounting bracket
• Reduced height slim construction
• Low noise – 23dBA on smaller models
• Back-up switch for loss of controller
• Cold draft prevention on heat pump start up
• Fault diagnosis
• Auto re-start after power interruption

Categories: , Tag: Product ID: 31764

Description

INDOOR UNIT c/w ControllerSKM35ZSP-W
Nominal CoolingKw3.5
Nominal HeatingKw4.5
Exterior Dimensions (H x W x D)mm267 x 783 x 212
Net Weightkg7.5
Air Flow (H/M/L) Coolingm3/m9.0 / 7.5 / 5.0
Air Flow (H/M/L) Heatingm3/m8.5 / 7.0 / 6.0
Sound Pressure Level (H/M/L) Coolingdb(A)44 / 37 / 25
Sound Pressure Level (H/M/L) Heatingdb(A)8.5 / 7.0 / 6.0
Ref. Piping Size o.d.ins (mm)Liquid1/4 (6.35)
Suction3/8 (9.52
OutdoorSCM100ZS-W
Power source (Outdoor)1 Phase 240V 50Hz
*Operation dataNominal Capacity (Range)Cooling T1kW10.0 (1.7~11.5)
Heating H110.5 (0.9~11.5)
Power consumptionCooling T12.70
Heating H12.38
Running currentCooling T1A11.4
Heating H110.0
Inrush current, maximum current5, 21
EERCooling T13.70
COPHeating H14.41
Sound power level (JIS C9612)Cooling T1dB(A)67
Heating H172
Sound pressure level (JIS C9612)Cooling T154
Heating H159
Silent modeCooling T149
Heating H150
External dimensions (HxWxD)mm945 x 970 x 370
Net weightkg73
Refrigerant (R32)Quantity2.98
Pre charged to pipe lengthm40
Installation dataRefrigerant pipingLiquid linemmØ6.35 x 5
Gas lineØ9.52 x 5
Connection methodFlare connection
Maximum pipe length to one indoor unitm25
Total pipe length to all indoor units75
Max vertical height diff. between O.U. and I.U.20 ( O.U. above I.U.)  / 20 ( O.U. below I.U. )
Indoor Unit Connection**3 to 5 Units
Indoor Connection CapacitykW9.0 to 16.0
Outdoor air temperature (upper, lower limits)Cooling°C-15 to 46
Heating-15 to 24
* Operation data are are conducted in accordance with  AS/NZS 3823 standard. For testing conditions please refer to Page14.
**  This model normally requires a minimum of 3 indoor units. Combination of 2 indoor units in some circumstances would be permitted. Please refer to the “Combination Limitations” table on page 10 for the detailed connection information.

These air conditioning units must be installed by an F-Gas qualified engineer. ( We will ask to view this certificate before the shipment) We can install the unit for you using our F-Gas Certified Engineers.
