Description
Technical Information:
Nominal Capacity Cooling kW – 12.5
Capacity (UK) Cooling kW – 12.5
Nominal Capacity (T1) Heating kW – 14.00
Power Supply to Unit V/Phase/Hz – 240/1/50
Power supply to – outdoor
Inter connecting Cables – 4*15
cores and rating No. Amps 5/20
Running Current Cooling Amps – 16.9
Running Current Heating Amps – 15.2
Power Input Cooling kW – 3.89
Power Input Heating kW – 3.49
Start Current Cooling Amps – <16
Start Current Heating Amps – <16
Circuit Breaker Amps – 40
T1 EER Cool (W/W) – 3.01
T1 COP Heat (W/W) – 3.75
ECA compliant – yes
Air Circulation Indoor – (m3/min) – 40
(High Speed) Outdoor – (m3/min) – 55
Sound Levels Indoor – dB(A)+/-3 (at 1.0m) – 38
(High Speed) Outdoor – dB(A)+/-3 (at 1.0m) – 52
Indoor Units WxHxD (mm) – 1250 x 270 x 700
Outdoor Units WxHxD (mm) – 950 x 1380 x 330
Indoor Units (Kg) – 37
Outdoor Units (Kg) – 92
Liquid (Inch) – 3/8
Suction (Inch) – 5/8
Drain (ID) (mm) – 16
Maximum Elevation (m) – 30
Max. Distance between In & Out (m) – 75
Factory charge (Kg) – 3.6
Charged for — m (m) – 7.5
Additional g/m (g/m) – 40
These air conditioning units must be installed by an F-Gas qualified engineer. ( We will ask to view this certificate before the shipment) We can install the unit for you using our F-Gas Certified Engineers.
