Description
| INDOORCooling | Min/Rated/Max | W | AC18BQ.NSK900/5000/5500 | |
| Capacity | Heating +7°C | Min/Rated/Max | W | 900/5800/6400 |
| Heating -7°C | Rated | W | 4200 | |
| Power Input | Cooling | Rated | W | 1562 |
| Heating +7°C | Rated | W | 1611 | |
| EER | W/W | 3.20 | ||
| S.E.E.R. | 7.0 | |||
| P design C | kW | 7 | ||
| COP | W/W | 3.2 | ||
| S.C.O.P. | 3.6 | |||
| P design H | kW | 3.9 | ||
| Label: Cooling (A++ to E Scale) A++ Heating (A++ to E Scale) A+ | ||||
| Annual Energy Consumption Cooling | kWh | 250 | ||
| Heating | kWh | 1270 | ||
| SleepLow | dBAdBA | 3134 | ||
| Cooling | 39 | |||
| Sound Pressure High dBA | 44 | |||
| Low dBA | 34 | |||
| Heating Medium dBA | 39 | |||
| High dBA | 44 | |||
| Sound Power Cooling High dBA | 34 | |||
| Sleep m3/min | 39 | |||
| Low m3/min | 44 | |||
| Cooling Medium m3/min | 13 | |||
| Air Flow Rate High m3/min | 14.5 | |||
| (Power) m3/min | 15.5 | |||
| Low m3/min | 11 | |||
| Heating Medium m3/min | 15.5 | |||
| High m3/min | 16.0 | |||
| Dehumidification Rate l/h | 1.8 | |||
| Cooling Rated A | 6.9 | |||
| Running Current Max A | 9.0 | |||
| Heating Rated A | 7.1 | |||
| Max A | 9.5 | |||
| Starting Current Cooling Rated A | 6.9 | |||
| Heating Rated A | 7.1 | |||
| Power Supply Ø / V /Hz | 1 / 220-240 / 50 | |||
| Circuit Breaker A | 15 | |||
| Power Supply Cable N x mm² | 3*1.0 | |||
| Power & Transmission Cable N x mm² | 4*1.0 (Including Earth) | |||
| Dimension mm | 998 x 345 x 210 | |||
| Net Weight kg | 9.9 | |||
| Fan Motor Output W | 30 | |||
Technical Specifications Outdoor Multi:
| OUTDOOR UNIT MU2R17 UL0 | |||
| Capacity * | Cooling | Min / Nom / Max kW | 0.9 / 4.7 / 5.4 |
| Heating | Min / Nom / Max kW | 1.0 / 5.3 / 5.7 | |
| Low Temperature Capacity Heating -7°C | Max kW | 3.7 | |
| Power Input * | Cooling | Min / Nom / Max kW | 0.2 / 1.3 / 1.7 |
| Heating | Min / Nom / Max kW | 0.2 / 1.3 / 1.6 | |
| Running Current | Cooling | Min / Nom / Max A | 1.1 / 5.6 / 7.9 |
| Heating | Min / Nom / Max A | 1.1 / 5.5 / 7.6 | |
| EER | 3.75 | ||
| COP | 4.22 | ||
| SEER | 7.80 | ||
| SCOP | 4.20 | ||
| Pdesign (@-10°C) | kW | 4.10 | |
| Seasonal Energy Label Cooling / Heating | A++ / A+ | ||
| Annual Energy Consumption Cooling / Heating | 210 / 1,367 | ||
| Airflow Rate Nom | m3/min | 28.2 | |
| Sound Pressure | Cooling | Nom dBA | 48 |
| Heating | Nom dBA | 51 | |
| Sound Power Cooling | Max dBA | 63 | |
| Dimensions W x H x D mm | 770 x 545 x 288 | ||
| Net Weight | Kg | 36 | |
| Refrigerant | Type | R32 | |
| Charge Kg | 1.1 | ||
| Additional Charge g/m | 20 | ||
| GWP | 675 | ||
| t-CO2 eq | 0.74 | ||
| Operation Range (Outdoor) | Cooling | Min ~ Max °C DB | -10 ~ 48 |
| Heating | Min ~ Max °C WB | -18 ~ 18 | |
| Power Supply | Ø / V / Hz | 1 / 220-240 / 50 | |
| Power Supply Cable | No. x mm2 | 3C x 2.5 | |
| Transmission Cable | No. x mm2 | 4C x 0.75 | |
| Circuit Breaker | A | 15 | |
| Piping Length Total | m | 30 | |
| Piping Length per Branch | Max m | 20 | |
| Piping Elevation Difference | IDU – ODU | Max m | 15 |
| IDU – IDU | Max m | 7.5 | |
| Piping Connection | Liquid mm (inch) x No. | Ø6.35 (1/4) x 2 | |
| Gas mm (inch) x No. | Ø9.52 (3/8) x 2 | ||
These air conditioning units must be installed by an F-Gas qualified engineer. ( We will ask to view this certificate before the shipment) We can install the unit for you using our F-Gas Certified Engineers
