Description
UNIT INDOOR 12K 0.89 / 3.50 / 4.04 Capacity Cooling / Rated / Max. kW Heating Min. / Rated / Max. kW 0.89 / 4.00 / 6.00 Heating -7°C Rated kW 3.50 Power Input Cooling / Heating Rated W 933 / 976 EER W/W 3.75 S.E.E.R. 7.60 P design C kW 3.50 COP W/W 4.10 S.C.O.P (Average / Warmer) 4.60 / 5.40 design H (Average / Warmer) kW 2.90 / 1.50 Energy Label (A+++ to D Scale) Cooling A++ Heating (Average / Warmer) A++ / A++ A n n u a l E n e r g y Consumption Cooling kWh 161 Heating / Warmer) kWh 883 / 389 Sound Pressure Cooling S / L / M / H dB(A) 19 / 27 / 37 / 42 Heating L / M / H dB(A) 27 / 37 / 42 Sound Power Cooling dB(A) 60 Air Flow Rate Cooling / L / M / H / Max. (Power) m3/min 3.5 / 5.5 / 9.0 /11.0 /13.0 Heating L / M / H m3/min 6.5 / 9.0 / 11.0 Dehumidification Rate l/h 1.3 Running Current Cooling / Rated / Max. A 1.00 / 4.00 / 6.00 Heating / Rated / Max. A 1.00 / 4.30 / 7.00 Starting Current Cooling / Heating Rated A 4.00 / 4.30 Power Supply Ø/ V/ Hz 1 / 220-240 / 50 Circuit Breaker A 15 Power Supply Cable N xmm2 3 x 1.0 Power & Transmission Cable N xmm2 4 x 1.0(Including Earth) Dimension mm 837 x 308 x 189 Net Weight kg 9.1 Fan Motor Output W 30 OUTDOOR Operation Range Cooling / Max. °C DB -15 / 48 Heating / Max. °C DB -15 / 24 Sound Pressure Cooling / Heating High dB(A) 49 / 51 Sound Power Cooling High dB(A) 65 Air Flow Rate High m3/min 35 Piping Liquid (ODU / IDU) / Max. m 3 / 20 Elevation (ODU / IDU) / Max. m 10 Piping Connection Liquid (Outside) mm (inch) 6.35 (1/4) Gas (Outside) mm (inch) 9.52 (3/8) Drain Hose Size (Outside) mm (inch) 21.5 (27/32) Refrigerant Type R32 Charge at 7.5m kg 0.800 t-CO2 eq 0.540 Additional Charge g/m 20 GWP 675 Fan Motor Output W 43 Compressor Type Inverter Twin Rotary Net Weight kg 34.1 Dimension mm 770 x 545 x 288
UNIT INDOOR 9K 0.89 / 2.50 / 3.70 Capacity Cooling / Rated / Max. kW Heating / Rated / Max. kW 0.89 / 3.20 / 5.00 Heating -7°C Rated kW 3.20 Power Input Cooling / Heating Rated W 572 / 711 EER W/W 4.37 S.E.E.R. 7.90 P design C kW 2.50 COP W/W 4.50 S.C.O.P (Average / Warmer) 4.60 / 5.40 design H (Average / Warmer) kW 2.80 / 1.50 Energy Label (A+++ to D Scale) Cooling A++ Heating (Average / Warmer) A++ / A++ A n n u a l E n e r g y Consumption Cooling kWh 111 Heating / Warmer) kWh 852 / 389 Sound Pressure Cooling S / L / M / H dB(A) 19 / 27 / 37 / 42 Heating L / M / H dB(A) 27 / 37 / 42 Sound Power Cooling dB(A) 60 Air Flow Rate Cooling / L / M / H / Max. (Power) m3/min 3.5 / 5.5 / 9.0 /11.0 /13.0 Heating L / M / H m3/min 6.5 / 9.0 / 11.0 Dehumidification Rate l/h 1.1 Running Current Cooling / Rated / Max. A 1.00 / 2.50 / 6.00 Heating / Rated / Max. A 1.00 / 3.20 / 7.00 Starting Current Cooling / Heating Rated A 2.50 / 3.20 Power Supply Ø/ V/ Hz 1 / 220-240 / 50 Circuit Breaker A 15 Power Supply Cable N xmm2 3 x 1.0 Power & Transmission Cable N xmm2 4 x 1.0(Including Earth) Dimension mm 837 x 308 x 189 Net Weight kg 9.1 Fan Motor Output W 30 OUTDOOR Operation Range Cooling / Max. °C DB -15 / 48 Heating / Max. °C DB -15 / 24 Sound Pressure Cooling / Heating High dB(A) 49 / 51 Sound Power Cooling High dB(A) 65 Air Flow Rate High m3/min 35 Piping Liquid (ODU / IDU) / Max. m 3 / 20 Elevation (ODU / IDU) / Max. m 10 Piping Connection Liquid (Outside) mm (inch) 6.35 (1/4) Gas (Outside) mm (inch) 9.52 (3/8) Drain Hose Size (Outside) mm (inch) 21.5 (27/32) Refrigerant Type R32 Charge at 7.5m kg 0.800 t-CO2 eq 0.540 Additional Charge g/m 20 GWP 675 Fan Motor Output W 43 Compressor Type Inverter Twin Rotary Net Weight kg 34.1 Dimension mm 770 x 545 x 288
Technical Specifications Outdoor Multi:
OUTDOOR UNIT MU2R15 UL0 Compressor Type Twin Rotary Capacity * Cooling Min / Nom / Max kW 0.9 / 4.1 / 4.7 Heating Min / Nom / Max kW 1.0 / 4.7 / 5.4 Low Temperature Capacity Heating -7°C Max kW 3.3 Power Input * Cooling Min / Nom / Max kW 0.2 / 1.0 / 1.4 Heating Min / Nom / Max kW 0.2 / 1.1 / 1.4 Running Current Cooling Min / Nom / Max A 1.1 / 4.6 / 6.4 Heating Min / Nom / Max A 1.1 / 4.9 / 6.6 EER 4.14 COP 4.38 SEER 8.50 SCOP 4.20 Pdesign (@-10°C) kW 4.10 Seasonal Energy Label Cooling / Heating A+++ / A+ Annual Energy Consumption Cooling / Heating 169 / 1,367 Airflow Rate Nom m3/min 28.2 Sound Pressure Cooling Nom dBA 48 Heating Nom dBA 51 Sound Power Cooling Max dBA 61 Dimensions W x H x D mm 770 x 545 x 288 Net Weight Kg 36 Refrigerant Type R32 Charge Kg 1.1 Additional Charge g/m 20 GWP 675 t-CO2 eq 0.74 Operation Range (Outdoor) Cooling Min ~ Max °C DB -10 ~ 48 Heating Min ~ Max °C WB -18 ~ 18 Power Supply Ø / V / Hz 1 / 220-240 / 50 Power Supply Cable No. x mm2 3C x 2.5 Transmission Cable No. x mm2 4C x 0.75 Circuit Breaker A 15 Piping Length Total m 30 Piping Length per Branch Max m 20 Piping Elevation Difference IDU – ODU Max m 15 IDU – IDU Max m 7.5 Piping Connection Liquid mm (inch) x No. Ø6.35 (1/4) x 2 Gas mm (inch) x No. Ø9.52 (3/8) x 2
These air conditioning units must be installed by an F-Gas qualified engineer. ( We will ask to view this certificate before the shipment) We can install the unit for you using our F-Gas Certified Engineers
