Description
Technical Specifications:
| Indoor Unit Model R32 | rak-42rpd | ||
| Nominal Cooling Capacity (min – max) | kW | 4.20 (1.70 – 5.00) | |
| Sensible Cooling Capacity | kW | 3.3 | |
| UK Cooling Capacity (sensible) | kW | 4.0 (3.2) | |
| Nominal Heating Capacity (min – max) | kW | 5.40 (1.70- 6.00) | |
| Nominal cooling power input (min – max) | kW | 1.12 (0.30 – 1.70) | |
| Nominal heating power input (min – max) | kW | 1.32 (0.50 – 2.10) | |
| Seasonal Effi SEER(4)Energy Effi Class Annual Energy Consumption | kWh/yr | 7.5 | |
| A++ | |||
| 196 | |||
| Seasonal Effi | SCOP(4) (Average Climate)Energy Effi Class Annual Energy Consumption | kWh/yr | 4.6 |
| A++ | |||
| 522 | |||
| Nominal Load Ef | fi EER / COP(5)Energy Class (Cool/Heat) | 3.75 / 4.10 | |
| A / A | |||
| Noise level cooling (sound pressure) (SL / L / M / H)(2) | dB(A) | 25 / 28 / 39 / 46 | |
| Noise level heating (sound pressure) (SL / L / M / H)(2) | dB(A) | 27 / 31 / 39 / 46 | |
| Noise level (sound power)(1) | dB(A) | 60 | |
| Air flow cooling mode (SL / L / M / H) | m3/h | 353 / 410 / 540 / 720 | |
| Air flow heating mode (SL / L / M / H) | m3/h | 380 / 500 / 610 /800 | |
| Dehumidification | l/h | 1.8 | |
| Dimensions (H x W x D) | mm | 280 x 780 x 230 | |
| Weight | kg | 8.5 | |
| Power supply | 230V / 1Ph / 50Hz | ||
| Drain diameter (ext) | φ16mm | ||
| Remote Control | Std | Infra Red (RAR-6N1) | |
| Opt | SPX-WKT3 / SPX-RCDB | ||
OUTDOOR UNITS
| Outdoor Unit Model | rac-42wpd | |
| Noise level cooling (sound pressure)(3) | dB(A) | 49 |
| Noise level heating (sound pressure)(3) | dB(A) | 50 |
| Noise level (sound power)(1) | dB(A) | 63 |
| Air fl w (Cooling / Heating) | m3/h | 2160 / 2160 |
| Dimensions (H x W x D) | mm | 600x792x299 |
| Weight | kg | 39.0 |
| Piping diameter (Liquid / Gas) | Inch | 1/4″ / 1/2″ |
| mm | 6.35 – 12.7 | |
| Minimum Piping Length | m | 3.0 |
| Maximum Piping Length / Height Difference | m | 20 / 10 |
| Current Quantity of Refrigerant | kg | 1.05 |
| Chargeless / Additional Refrigerant Charge | m / g/m | 20 / – |
| Power supply | 230V / 1Ph / 50Hz | |
| Recommended fuse size | A | 25 |
| Starting current | A | 6.0 |
| Running current (cooling/heating) | A | 1.30-7.39 / 2.17-8.70 |
| Interconnecting Cables | No. | 1.50x 3+EARTH |
| Working Range (cooling/heating) | °C | -10°C~+43°C / -15°C~+21°C |
| Refrigerant / GWP | R32 / 675 | |
| Compressor type | Rotary | |
| System Price | (£) | 1,022 |
These air conditioning units must be installed by an F-Gas qualified engineer. ( We will ask to view this certificate before the shipment) We can install the unit for you using our F-Gas Certified Engineers
