Description
Key Features
Heat Recovery Ventilation
Recovers both sensible and latent heat through an air-to-air cross-flow heat exchanger using specially treated non-flammable High Efficiency Paper (HEP).
Energy-Efficient Operation
Equipped with a DC fan motor to reduce electricity consumption.
Filter change indication system monitors actual contamination levels.
Supports free cooling operation when outdoor temperature is lower than indoor, ideal for overnight ventilation.
Flexible Installation & Integration
Use standalone or integrate with Sky Air or VRV systems.
No drain piping required, reducing installation complexity.
Automatic ESP (External Static Pressure) adjustment saves commissioning time.
Optional Enhancements
CO₂ sensor integration to avoid over-ventilation and improve indoor air quality.
Optional dust filters available:
ePM10 70% (M6)
ePM1 55% (F7)
ePM1 70% (F8)
Technical Specifications
Category
Specification
Airflow Rate
500 m³/h (Bypass & Heat Exchange – Ultra High)
External Static Pressure
90 Pa (Ultra High)
Operating Modes
Heat Exchange, Bypass, Fresh-up
Heat Exchange System
Total heat (sensible + latent)
Heat Exchanger Material
Specially processed non-flammable paper
Temperature Range
-10°C to 46°C (dry bulb), RH ≤ 80%
Power Input (Nominal)
0.148 kW (Bypass), 0.164 kW (Heat Exchange)
Sound Power Level (Lwa)
54 dB
Sound Pressure Level
38.0 dBA (Bypass), 37.5 dBA (Heat Exchange)
Connection Duct Diameter
200 mm
Unit Dimensions (WxHxD)
1113 × 305 × 866 mm
Casing Material
Galvanised steel plate
Weight
46.5 kg
Power Supply
1~, 220–240 V, 50/60 Hz
