Description
Highlights
Ventilation with Heat Recovery as Standard
Free Cooling – Utilises cooler outdoor air when available (e.g. nighttime)
Energy Efficient DC Fan Motor – Minimises power consumption
Automatic ESP Control – Faster setup, no need for manual damper balancing
Filter Maintenance Alerts – Based on actual filter contamination
Wide Operating Range – Down to -10°C ambient
Flexible Use – Standalone or integrated into larger HVAC systems
No Drain Pipe Required
Advanced Air Quality Options
Optional CO₂ sensors to reduce energy waste from over-ventilation
Optional medium and fine dust filters to meet regulatory or user-specific standards:
ePM10 70% (M6)
ePM1 55% (F7)
ePM1 70% (F8)
Core Product Features
Crossflow Total Heat Exchanger
Transfers both sensible and latent heat using high-efficiency, non-flammable HEP (High Efficiency Paper)
Three Operation Modes
Heat Exchange Mode
Bypass Mode
Fresh-Up Mode
Installation-Friendly Design
Shorter installation times due to nominal airflow pre-adjustment
Reduces need for additional dampers
Can operate in over- or under-pressure configurations
Technical Specifications
Specification
Details
Airflow (Ultra High)
1,500 m³/h (heat exchange & bypass mode)
External Static Pressure
90 Pa
Power Input (Nominal)
0.525 kW (Bypass), 0.548 kW (Heat Exchange)
Heat Exchange Type
Crossflow (sensible + latent)
Filter Change Indicator
Yes
Noise Levels (Sound Pressure)
42 dBA (Bypass & Heat Exchange)
Noise Level (Sound Power)
62 dB
Operating Temp Range
-10°C to 46°C (dry bulb)
Humidity Limit
80% RH or less
Duct Connection Diameter
2 × 250 mm
Casing Material
Galvanised steel
Power Supply
1~, 220–240 V, 50/60 Hz
Dimensions (W × H × D)
1,354 × 731 × 1,172 mm
Unit Weight
160 kg
