Description
INDOOR UNITS:
Power source 1 ph 240V
Type Inverter controlled
COOLING (nominal) max. kW 3.5 / 12000 BTU
HEATING (nominal) max. kW 4.2 / 14000 BTU
UK Cooling (max) kW 3.2
UK Sensible Cooling kW 4
E.E.R.
Energy label in heating A
Energy label in cooling A
C.o.P 3.41
ECA – Yes
Exterior dimensions (mm) 254x840x840 Panel dimensions (mm) 950c950x288
Net weight kg 18
Sound Pressure Level* (cooling) dB(A) 28 / 34.5
Sound Pressure Level* (heating) dB(A) 28 / 34.5
OUTDOOR UNIT:
Model – 4MXS80E
Power source 1 ph 240v
Type Inverter
COOLING (nominal) max. kW 8.00 (1.0~8.0)
HEATING (nominal) max. kW 9.6 (0.95~9.6)
E.E.R. n/a
Energy label in heating A
Energy label in cooling A
C.o.P 3.65
Exterior dimensions (mm) 770x900x320
Net weight kg 72
Power Source Rating MCB A 20A
Refrigerant max piping length m 70
4 X pipe service connections
Pipe sizes – 4 x 1/4″, 2 x 3/8″/1/2″ , 2 x 5/8
These air conditioning units must be installed by an F-Gas qualified engineer. ( We will ask to view this certificate before the shipment) We can install the unit for you using our F-Gas Certified Engineers.
